Electric strike lock, 12-24V AC/DC
“ABB RDCU Drive Control” has been added to your cart. Continue shopping
Electric strikes are building access control devices used on doors. Instead of a mechanical locking mechanism, electrified strikes operate by a powered command that causes the door to lock or unlock.
- 24x7 Support +968 99 26 36 46
- Premium Quality
- 10 days Return & Exchange
- Deliver in 5-7 Days
- Worldwide Shipping
- Sellers can Quote
Description
12-24V AC/DC. AC-12V: 425mA, AC-24V: 940mA, DC-12V: 550mA, DC-24V:1060mA.
Parameters
- Completely surface mounted
- Stainless steel construction
- Tamper resistant
- Horizontal adjustment
The 24V DC Fail Secure Electric Strike Lock offers reliable security with multiple power options, including 12V AC/DC or 24V DC. Featuring a “B” function for mechanical unlatching, it is suitable for left and right-hand opening doors. Compatible with aluminum, wooden, and hollow metal doors, it offers versatility in installation. The lock can be operated using cards, keys, pass cords, remote controls, and push-button switches, providing convenient access control options. Choose between Fail Safe (released as power off) or Fail Secure (released as energized) models, both CE approved for safety and quality assurance.
| Model Number | ES125 |
|---|---|
| Minimum Order Quantity | 200 pieces |
| Port | Kaohsiung |
- 12V AC/DC or 24V DC available
- Mechanical Unlatching. (“B” Function)
- Suitable for Opening by Left and Right
- Fits for aluminum door, wooden door and hollow metal door
- Workable with card, key, passcord, remote control and push button switch
Power sources can be AC (alternating current) or DC (direct current). In the context of electrified hardware, AC power is intended for intermittent duty (like momentary unlocking for an apartment main entry) while DC power is used for continuous duty (like an access control system for an office building’s main entry doors.) Most applications in today’s access control systems are DC supply.
However, it is important to consider if the device requires a 12-voltage or 24-voltage power source. Depending on the manufacturer and model, they can be:
- 12-volt only
- 24-volt only
- 12-volt OR 24-volt
- 12-volt TO 24-volt
Let’s take an example. An HES 9600 electric strike can draw power from either a 12-volt or a 24-volt power source. It draws current equal to 0.45 amps at 12-volt, but only 0.25 amps at 24-volt. These numbers indicate a requirement of about half an amp at 12-volt but just one-quarter of an amp at 24-volt. How is this useful? If you start adding multiple devices, it stands to reason that if you are able to run them all on 24-volt, you can run more devices off of a power supply that supplies 24-volt than one that supplies 12-volt.
In our listed example, let’s say we want to run two HES 9600 electric strikes off of a 1-amp power supply. If you run them at 12-volt, you would use 0.90 amps – almost all of it – but if you run them at 24-volt, you would only be using 0.50 amps, which would allow you to add a third strike, if desired. Please note that it is not recommended to exceed 75-80% of the total current of the power supply; so in this example, don’t add a fourth strike.
